Power Transmission

In the power grid sector, Firstack gate drivers serve as the core control units for HVDC (High-voltage Direct Current) and high-voltage SVG (Static Var Generator) systems. By precisely driving IGBT power modules, they ensure the efficient and stable operation of power transmission and reactive power compensation.
The products integrate multiple protection functions such as short-circuit protection, overcurrent protection, and undervoltage protection.

Part Number	Application	Description	Max Breakdown Voltage	Power Switch
2FHD0115C	Rail Motor Drives Other Industrial Power Transmission	● 1.2W/20A,for EconoDual ● 2-level topology ● Electrical interface ● SSD, Active clamping	1700V	IGBT
HV1027P	Rail Motor Drives Power Transmission	● Single channel, 3W / 27A, for IHV module ● Multi-level topology ● SSD, Vce detection, Active clamping, MLTO	4500V, 6500V	IGBT
SK08110	Rail Motor Drives Power Transmission	● Single channel, 8W / 110A for Press Pack, Stakpak ● Multi-level topology ● SSD, di/dt, UVLO, Advanced active clamping, Highly robust DC/DC, NTC Sampling	4500V	IGBT
